Main advantages :
The interlock of Z sheet pile is symmetrically located on each side of the eneutral axis, coulped with the advantages of the continuous form of the web, this desigh greatly improve the section modulus and guaranctee a excellent mechanical properties.
Large width, good pile sinsheet performance.
large section modulus
Increased inertia for reduced deflection ,strenthen the stiffness and reduce the risk of structural deformation
Good corrosion resistance
All of our sheet piles according EN10025,EN10249 standards.
SECTION TYPE |
Width | Height | Thickness | Section | Weight | Weight | Moment of | Moment of |
w | h | t | Area | perpilr | per wall | Inertia | Scetion | |
mm | mm | mm | cm2/m | kg/m | kg/m2 | cm4/m | cm3/m | |
SLZ13-1 | 670 | 303 | 9.5 | 137 | 72 | 107 | 19700 | 1300 |
SLZ13-2 | 770 | 344 | 9 | 126 | 76.1 | 99 | 22360 | 1300 |
SLZ13-3 | 575 | 260 | 10.8 | 150.3 | 67.9 | 118 | 16250 | 1250 |
SLZ14-1 | 670 | 304 | 10.5 | 149 | 78.3 | 117 | 21300 | 1400 |
SLZ14-2 | 770 | 345 | 9.5 | 132 | 79.5 | 103 | 23300 | 1355 |
SLZ14-3 | 770 | 345 | 10 | 137 | 82.9 | 108 | 24240 | 1405 |
SLZ17-3 | 575 | 370 | 8.5 | 142.8 | 64.5 | 112 | 28890 | 1655 |
SLZ17-4 | 575 | 370 | 9 | 148.2 | 66.9 | 116 | 30110 | 1725 |
SLZ17-5 | 575 | 350 | 9.5 | 149 | 67.3 | 117 | 29760 | 1705 |
SLZ14-4 | 700 | 420 | 7 | 112.8 | 62 | 88.6 | 30910 | 1480 |
SLZ14-5 | 650 | 320 | 8 | 127.4 | 65 | 100 | 22049 | 1380 |
